ALTIC HRTI 800

UGAM Technology’s ALTIC HRTI 800 is an advanced silicone-based heat-resistant ceramic coating engineered for industrial applications that demand superior protection against extreme heat and corrosion. Designed to perform under continuous temperatures up to 800°C, this coating provides a unique combination of thermal insulation, reflectivity, and mechanical durability, making it one of the most efficient solutions for high-temperature surface protection.

This innovative product not only extends the lifespan of metallic components but also helps industries achieve energy efficiency by reflecting radiant heat and reducing surface temperatures. It is an ideal choice for heavy-duty applications in furnaces, boilers, exhaust systems, chimneys, heat exchangers, pipelines, and process equipment.

---

Key Features and Advantages

1. High Heat Resistance
   ALTIC HRTI 800 withstands continuous exposure to temperatures up to 800°C, ensuring long-lasting protection for steel and other metallic surfaces operating under severe heat conditions.

2. Thermal Insulation Efficiency
   The coating is designed to reduce heat transfer by reflecting and dissipating radiant energy. This contributes to energy conservation and surface temperature control, making it an ideal solution for energy-sensitive industrial setups.

3. Single-Pack Ready-to-Use Formula
   ALTIC HRTI 800 is a single-component paint, simplifying application and storage. It requires no catalyst or primer, reducing preparation time and cost.

4. Excellent Adhesion and Flexibility
   The coating forms a strong bond with the substrate while maintaining flexibility to withstand thermal expansion and contraction cycles without cracking or peeling.

5. Corrosion and Chemical Resistance
   The formulation offers excellent resistance against grease, oil, mild acids, alkalis, and solvents, providing comprehensive protection even in aggressive industrial environments.

6. Weather and UV Stability
   Its silicone resin base ensures outstanding durability and weather resistance, maintaining appearance and performance even after prolonged outdoor exposure.

7. Easy Application
   ALTIC HRTI 800 can be applied using a brush or spray, providing a smooth matte finish. Its self-priming property eliminates the need for a separate primer coat.

8. Energy Saving and Sustainability
   By minimizing heat loss and extending component life, this coating contributes to reduced maintenance costs and improved operational efficiency, aligning with modern sustainability goals.

---

Technical Specifications

---

Performance Test Results

---

Chemical and Environmental Resistance

• Acids: Fair to Good
• Alkalis: Fair to Good
• Solvents: Poor (Splash) / Good (Outdoor)
• Salt & Water: Excellent
• Weatherability: Very Good
• Abrasion Resistance: Good

---

Surface Preparation

Before application, surfaces must be clean, dry, and free of oil, grease, rust, and old coatings.

1. Degrease the surface using a suitable solvent.

2. For optimal performance, blast clean to a minimum of Sa 2½ (Swedish Standard SIS 05 5900).

3. If blasting is not possible, use mechanical tools and wire brushing to reach St 2.

4. Remove dust and contaminants before painting.

Proper surface preparation ensures maximum adhesion and coating longevity.

---

Application Procedure

1. Mixing: Stir the paint thoroughly to a uniform consistency. Thin with ALTIC HR Thinner if required.

2. Application: Apply evenly by brush or spray. No primer is required.

3. Curing:

   • Air dry for 1 hour.

   • Heat and maintain at 250°C for 1 hour per coat.

   • Apply a total of three coats, each cured as above.

4. Final Curing: After the last coat, gradually increase the temperature at 100°C per hour until reaching the working temperature.

5. Coverage: Approx. 100 sq. ft. per liter per coat, depending on the surface condition.

During initial heating, slight fuming may occur — this is normal due to the curing of the silicone matrix.

---

Safety and Handling

• Avoid application below 10°C or above 50°C.
• Do not apply during rain, fog, or high humidity (>90%).
• Ensure proper ventilation during application and drying.
• Clean tools immediately after use with ALTIC HR Thinner.
• Store sealed containers in a cool, dry, and ventilated area.

---

Applications

ALTIC HRTI 800 is widely used in industries requiring thermal protection and energy efficiency, including:

• Furnace and oven surfaces
• Boiler exteriors
• Exhaust pipes and silencers
• Chimney stacks
• Industrial reactors
• Heat exchangers
• Hot pipelines and ducts
• Power generation equipment

---

Conclusion

ALTIC HRTI 800 from UGAM Technology is a cutting-edge high-temperature silicone ceramic paint that provides unmatched protection and insulation for metallic surfaces exposed to intense heat. Its high reflectivity, corrosion resistance, and superior mechanical properties make it ideal for extending the life of industrial components while promoting energy savings and operational reliability.

Engineered with precision and backed by ISO 9001:2015 quality assurance, ALTIC HRTI 800 ensures top-tier performance across diverse industrial environments, making it a preferred choice for professionals seeking durability, efficiency, and sustainability in heat-resistant coatings.
